Static Aggregation Group Configuration
The Aggregation Group Configuration screen in Figure 4-5-3 appears.
Figure 4-5-3: Aggregation Group Configuration page Screenshot
The page includes the following fields:
.Object Description
• Group ID
Indicates the group ID for the settings contained in the same row. Group ID
"Normal" indicates there is no aggregation. Only one group ID is valid per port.
• Port Members
Each switch port is listed for each group ID. Select a radio button to include a port
in an aggregation, or clear the radio button to remove the port from the
aggregation. By default, no ports belong to any aggregation group.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.5.2 LACP Configuration
Link Aggregation Control Protocol (LACP) - LACP LAG negotiate Aggregated Port links with other LACP ports located on a
different device. LACP allows switches connected to each other to discover automatically whether any ports are member of the
same LAG.
