Planet IGS-10020 Series - Detailed MEP Configuration

User’s Manual
375
Buttons
: Click to add a new MEP entry
: Click to refresh the page immediately.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.20.2 Detailed MEP Configuration
This page allows the user to inspect and configure the current MEP Instance.; screen in Figure 4-20-2 appears.
Figure 4-20-2: Detail MEP configuration page screenshot
The page includes the following fields:
Instance Data:
Object Description
• Instance
The ID of the MEP.
• Domain
See help on MEP create WEB.
• Mode
See help on MEP create WEB.
• Direction
See help on MEP create WEB.
• Residence Port
See help on MEP create WEB.
• Flow Instance
See help on MEP create WEB.
