User’s Manual
• Tagged VID
See help on MEP create WEB.
• This MAC
See help on MEP create WEB.
Instance Configuration:
Object Description
• Level
See help on MEP create WEB.
• Format
This is the configuration of the two possible Maintenance Association Identifier
formats.
ITU ICC: This is defined by ITU. 'ICC' can be max. 6 char. 'MEG id' can be max. 7
char.
IEEE String: This is defined by IEEE. 'Domain Name' can be max. 8 char. 'MEG
id' can be max. 8 char.
• Domain Name
This is either ITU ICC (MEG ID value[1-6]) or IEEE Maintenance Domain Name -
depending on 'Format'. See 'Format'.
• MEG Id
This is either ITU UMC (MEG ID value[7-13]) or IEEE Short MA Name -
depending on 'Format'. See 'Format'. In case of ITU ICC format this can be max.
7 char. If only 6 char. is entered the MEG ID value[13] will become NULL.
• MEP Id
This value will become the transmitted two byte CCM MEP ID.
• cLevel
Fault Cause indicating that a CCM is received with a lower level than the
configured for this MEP.
• cMEG
Fault Cause indicating that a CCM is received with a MEG ID different from
configured for this MEP.
• cMEP
Fault Cause indicating that a CCM is received with a MEP ID different from all
'Peer MEP ID' configured for this MEP.
• cAIS
Fault Cause indicating that AIS PDU is received.
• cLCK
Fault Cause indicating that LCK PDU is received.
• cSSF
Fault Cause indicating that server layer is indicating Signal Fail.
• aBLK
The consequent action of blocking service frames in this flow is active.
• aTSF
The consequent action of indicating Trail Signal Fail to-wards protection is active.
• Delete
This box is used to mark a Peer MEP for deletion in next Save operation.
• Peer MEP ID
This value will become an expected MEP ID in a received CCM - see 'cMEP'.
• Unicast Peer MAC
This MAC will be used when unicast is selected with this peer MEP. Also this
MAC is used to create HW checking of receiving CCM PDU (LOC detection) from
t h i s M E P.
• cLOC
Fault Cause indicating that no CCM has been received (in 3,5 periods) - from this
