User’s Manual
195
If an aggregation member port is selected as a router port, the whole aggregation
will act as a router port. The allowed selection is Auto, Fix, Fone, default
compatibility value is Auto.
• Fast Leave
Enable the fast leave on the port.
• Throtting
Enable to limit the number of multicast groups to which a switch port can belong.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.8.11 MLD Snooping VLAN Configuration
Each page shows up to 99 entries from the VLAN table, default being 20, selected through the "entries per page" input field.
When first visited, the web page will show the first 20 entries from the beginning of the VLAN Table. The first displayed will be
the one with the lowest VLAN ID found in the VLAN Table.
The "VLAN" input fields allow the user to select the starting point in the VLAN Table. The MLD Snooping VLAN Configuration
screen in Figure 4-8-14 appears.
Figure 4-8-14: IGMP Snooping VLAN Configuration page Screenshot
The page includes the following fields:
Object Description
• Delete
Check to delete the entry. The designated entry will be deleted during the next
save.
• VLAN ID
The VLAN ID of the entry.
• MLD Snooping Enable
Enable the per-VLAN MLD Snooping. Up to 32 VLANs can be selected for MLD
Snooping.
• Querier Election
Enable to join MLD Querier election in the VLAN. Disable to act as a MLD
Non-Querier.
