4.9.6.1 QoS Egress Port Tag Remarking
The QoS Egress Port Tag Remarking for a specific port are configured on this page. The QoS Egress Port Tag Remarking
screen in Figure 4-9-7 appears.
Figure 4-9-7: QoS Egress Port Tag Remarking page Screenshot
The page includes the following fields:
Object Description
• Mode
Controls the tag remarking mode for this port.
■ Classified: Use classified PCP/DEI values.
■ Default: Use default PCP/DEI values.
■ Mapped: Use mapped versions of QoS class and DP level.
• PCP/DEI Configuration
Controls the default PCP and DEI values used when the mode is set to Default.
• (QoS class, DP level)
to (PCP, DEI) Mapping
Controls the mapping of the classified (QoS class, DP level) to (PCP, DEI) values
when the mode is set to Mapped.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
