Planet IGS-10020 Series - DHCP Relay Statistics

User’s Manual
89
 Replace: Replace the original relay information when receiving a DHCP
message that already contains it.
 Keep: Keep the original relay information when receiving a DHCP message
that already contains it.
 Drop: Drop the package when receiving a DHCP message that already
contains relay information.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
4.2.10 DHCP Relay Statistics
This page provides statistics for DHCP relay. The DHCP Relay Statistics screen in Figure 4-2-12 appears.
Figure 4-2-12: DHCP Relay Statistics page Screenshot
The page includes the following fields:
Server Statistics
Object Description
• Transmit to Server
The packets number that is relayed from client to server.
• Transmit Error
The packets number whose errors are sending to clients.
• Receive from Server
The packets number that is received from server.
• Receive Missing Agent
Option
The packets number that is received without agent information options.
• Receive Missing
Circuit ID
The packets number whose missing circuit ID is received.
