4.11.9 RADIUS Details
This page provides detailed statistics for a particular RADIUS server. The RADIUS Authentication/Accounting for Server
Overview screen in Figure 4-11-10 appears.
Figure 4-11-10: RADIUS Authentication/Accounting for Server Overview page Screenshot
The page includes the following fields:
RADIUS Authentication Statistics
The statistics map closely to those specified in RFC4668 - RADIUS Authentication Client MIB. Use the server select box to
switch between the backend servers to show details for.
Object Description
• Packet Counters
RADIUS authentication server packet counter. There are seven receive and four transmit
counters.
Direction Name RFC4668 Name Description
