Planet IGS-10020 Series User Manual

User’s Manual
279
The page includes the following fields:
RADIUS Authentication Server Status Overview
Object Description
• #
The RADIUS server number. Click to navigate to detailed statistics for this server.
• IP Address
The IP address and UDP port number (in <IP Address>:<UDP Port> notation) of this server.
• Status
The current state of the server. This field takes one of the following values:
 Disabled: The server is disabled.
 Not Ready: The server is enabled, but IP communication is not yet up and running.
 Ready: The server is enabled, IP communication is up and running, and the RADIUS
module is ready to accept access attempts.
 Dead (X seconds left): Access attempts were made to this server, but it did not reply
within the configured timeout. The server has temporarily been disabled, but will get
re-enabled when the dead-time expires. The number of seconds left before this occurs
is displayed in parentheses. This state is only reachable when more than one server is
enabled.
RADIUS Accounting Server Status Overview
Object Description
• #
The RADIUS server number. Click to navigate to detailed statistics for this server.
• IP Address
The IP address and UDP port number (in <IP Address>:<UDP Port> notation) of this server.
• Status
The current state of the server. This field takes one of the following values:
 Disabled: The server is disabled.
 Not Ready: The server is enabled, but IP communication is not yet up and running.
 Ready: The server is enabled, IP communication is up and running, and the RADIUS
module is ready to accept accounting attempts.
Dead (X seconds left): Accounting attempts were made to this server, but it did not reply within
the configured timeout. The server has temporarily been disabled, but will get re-enabled
when the dead-time expires. The number of seconds left before this occurs is displayed in
parentheses. This state is only reachable when more than one server is enabled.
Buttons
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediately.
