Alarm
One relay output for power failure. Alarm Relay current carry ability: 1A @ 24V AC
DI and DO -
2 Digital Input (DI)
:
Level 0:
-24V~2.1V (±0.1V)
Level 1: 2.1V~24V (
±0.1V)
Input Load to 24V DC,
10mA max.
2 Digital Output (DO):
Open collector to 24V DC,
100mA (max.)
2 Digital Input (DI)
:
Level 0:
-24V~2.1V (±0.1V)
Level 1: 2.1V~24V
(±0.1V)
Input Load to 24V DC,
10mA max.
2 Digital Output (DO):
Open collector to 24V DC,
100mA (max.)
Dimensions (W x D x H)
56 x 87.8 x 135mm
72 x 107 x 152mm
72 x 107 x 152mm
Weight
720g 1010g 1043g
Power Requirements
12V to 48V DC
24V AC
12V to 72V DC
24V AC
9V to 48V DC
24V AC
Power Consumption
10 watts/34BTU (Full
loading)
6.5 watts/22.18BTU
(System on)
12 watts/40.95BTU (Full
loading)
8 watts/27BTU (System
on)
17 watts/57BTU (Full
loading)
LED Indicator
System:
Power 1 (Green)
Power 2 (Green)
Fault Alarm (Green)
Ring (Green)
R.O. (Green)
Per 10/100/1000T RJ45 Port:
1000 LNK/ACT (Green)
10/100 LNK/ACT (Orange)
Per SFP Interface:
1000 LNK/ACT (Green)
100 LNK/ACT (Orange)
Layer 2 Functions
Basic Management Interfaces
Web browser; Remote Telnet; SNMPv1, v2c
Secure Management Interface
SSH, SSL, SNMPv3
Port Configuration
Port disable/enable
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection
Flow Control disable/enable
Power saving mode control
Port Status
Display each port’s speed duplex mode, link status, Flow control status. Auto
negotiation status, trunk status.
Port Mirroring
TX/RX/Both
Many to 1 monitor
VLAN
802.1Q tagged-based VLAN, up to 255 VLAN groups
Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
MVR (Multicast VLAN Registration)
Up to 255 VLAN groups, out of 4095 VLAN IDs

Planet IGS-10020 Series Specifications

General

Brand	Planet
Model	IGS-10020 Series
Category	Network Router
Language	English
