User’s Manual
a. OUI: OUI (Organizationally Unique Identifier) is value in format of
xx-xx-xx where each pair (xx) in string is a hexadecimal value
ranges from 0x00-0xff.
b. PID: If the OUI is hexadecimal 000000, the protocol ID is the
Ethernet type (EtherType) field value for the protocol running on top
of SNAP; if the OUI is an OUI for a particular organization, the
protocol ID is a value assigned by that organization to the protocol
running on top of SNAP.
In other words, if value of OUI field is 00-00-00 then value of PID will be
etype (0x0600-0xffff) and if value of OUI is other than 00-00-00 then valid
value of PID will be any value from 0x0000 to 0xffff.
• Group Name
A valid Group Name is a unique 16-character long string for every entry which
consists of a combination of alphabets (a-z or A-Z) and integers(0-9).
Note: special character and underscore(_) are not allowed.
• Adding a New Group to
VLAN mapping entry
Click “Add New Entry”to add a new entry in mapping table. An empty row is
added to the table; Frame Type, Value and the Group Name can be configured
as needed.
The “Delete” button can be used to undo the addition of new entry.
Buttons
: Click to add a new entry in mapping table.
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Click to refresh the page immediately.
