Planet IGS-10020 Series User Manual

User’s Manual
17
the network bandwidth
 Storm Control support
− Broadcast/Multicast/Unknown Unicast
 Supports VLAN
− IEEE 802.1Q tagged VLAN
− Up to 255 VLANs groups, out of 4095 VLAN IDs
− Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
− Private VLAN Edge (PVE)
− Protocol-based VLAN
− MAC-based VLAN
− Voice VLAN
 Supports Spanning Tree Protocol
− IEEE 802.1D Spanning Tree Protocol (STP)
− IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
− IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) by VLAN
− BPDU Guard
 Supports Link Aggregation
− 802.3ad Link Aggregation Control Protocol (LACP)
− Cisco ether-channel (static trunk)
 Provides port mirror (many-to-1)
 Port mirroring of the incoming or outgoing traffic on a particular port
 Loop protection to avoid broadcast loops
 Supports E.R.P.S. (Ethernet Ring Protection Switching)
 IEEE 1588 and synchronous Ethernet network timing (IGS-12040MT, IGS-20040MT)
 Quality of Service
 Ingress Shaper and Egress Rate Limit per port bandwidth control
 8 priority queues on all switch ports
 Traffic classification
- IEEE 802.1p CoS
- IP TOS/DSCP/IP Precedence
- IP TCP/UDP port number
- Typical network application
 Strict priority and Weighted Round Robin (WRR) CoS policies
 Supports QoS and In/Out bandwidth control on each port
 Traffic-policing policies on the switch port
 DSCP remarking
 Multicast
 Supports IPv4 IGMP snooping v1, v2 and v3
 Supports IPv6 MLD snooping v1 and v2
 Querier mode support
 IGMP snooping port filtering
 MLD snooping port filtering
 MVR (Multicast VLAN Registration)
