User’s Manual
This page provides MVR related configuration. The MVR screen in Figure 4-8-19 appears.
Figure 4-8-19: MVR Configuration page Screenshot
The page includes the following fields:
Object Description
• MVR Mode
Enable/Disable the Global MVR.
The Unregistered Flooding control depends on the current configuration in
IGMP/MLD Snooping.
It is suggested to enable Unregistered Flooding control when the MVR group
table is full.
• Delete
Check to delete the entry. The designated entry will be deleted during the next
save.
• MVR VID
Specify the Multicast VLAN ID.
Caution: MVR source ports are not recommended to be overlapped with
management VLAN ports.
• MVR Name
MVR Name is an optional attribute to indicate the name of the specific MVR
VLAN. Maximum length of the MVR VLAN Name string is 16. MVR VLAN Name
can only contain alphabets or numbers. When the optional MVR VLAN name is
