Planet IGS-10020 Series User Manual

User’s Manual
24
Power Consumption
161.9 watts/522.08BTU
(Full loading with PoE
function)
306 watts/1043.46BTU
(Full loading with PoE
function)
349 watts/1190.83BTU
(Full loading with PoE
function)
LED Indicator
System:
Power 1 (Green)
Power 2 (Green)
Fault Alarm (Green)
Ring (Green)
R.O. (Green)
Per 10/100/1000T RJ45 Port:
LNK/ACT (Green)
PoE-in-Use (Orange)
Per SFP Interface:
LNK/ACT (Green)
1000 (Orange)
Power Over Ethernet
PoE Standard
IEEE 802.3af Power over
Ethernet/PSE
IEEE 802.3af/IEEE 802.3at Power over Ethernet/PSE
PoE Power Supply Type
End-span
PoE Power Output
Per Port 48V DC, 350mA .
Max. 15.4 watts
Per Port 56V DC, 350mA . Max. 15.4 watts (IEEE
802.3af)
Per Port 56V DC, 590mA. Max. 36 watts (IEEE 802.3at)
Power Pin Assignment
1/2(+), 3/6(-)
PoE Power Budget
130W maximum
(depending on power
input)
270W maximum
(depending on power
input)
320W maximum
(depending on power
input)
Max. number of Class 2 PDs
8
16
Max. number of Class 3 PDs
8
16
Max. number of Class 4 PDs
Not supported
8
10
Layer 2 Functions
Basic Management Interfaces
Web browser; remote Telnet; SNMPv1, v2c; local console
Secure Management Interface
SSH, SSL, SNMPv3
Port Configuration
Port disable/enable
Auto-negotiation 10/100/1000Mbps full and half duplex mode selection
Flow Control disable/enable
Port Status
Display each port’s speed duplex mode, link status, flow control status, auto
negotiation status, and trunk status.
Port Mirroring
TX/RX/Both
Many to 1 monitor
VLAN
802.1Q tagged-based VLAN, up to 255 VLAN groups
Q-in-Q tunneling
Private VLAN Edge (PVE)
MAC-based VLAN
Protocol-based VLAN
Voice VLAN
MVR (Multicast VLAN Registration)
Up to 255 VLAN groups, out of 4095 VLAN IDs
Link Aggregation
IEEE 802.3ad LACP/static trunk
