Planet IGS-10020 Series User Manual

User’s Manual
23
IGS-10020PT/IGS-10020HPT/IGS-20160HPT
Model Name
IGS-10020PT
IGS-10020HPT
IGS-20160HPT
Hardware Specifications
Copper Ports 8 10/100/1000BASE-T RJ45 Auto-MDI/MDI-X ports
18 10/100/1000BASE-T
RJ45 Auto-MDI/MDI-X
ports
SFP/mini-GBIC Slots
2 1000BASE-SX/LX/BX SFP interfaces (Port-9 to
Port-10)
Compatible with 100BASE-FX SFP
2 1000BASE-SX/LX/BX
SFP interfaces (Port-19 to
Port-20)
Compatible with
100BASE-FX SFP
PoE Injector Ports
8 ports with 802.3at/af PoE injector function with Port-1
to Port-8
16 ports with 802.3at/af
PoE injector function with
Port-1 to Port-16
Console
1 x RJ45 serial port (115200, 8, N, 1)
Switch Architecture
Store-and-Forward
Switch Fabric
20Gbps/non-blocking 40Gbps/non-blocking
Throughput (packet per second)
14.8Mpps@64Bytes
29.7Mpps@64Bytes
Address Table
8K entries, automatic source address learning and ageing
Shared Data Buffer
4Mbits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame
9Kbytes
Reset Button
< 5 sec: System reboot
> 5 sec: Factory Default
ESD Protection
6KV DC
Enclosure
IP30 aluminum case
Installation
DIN rail kit and wall-mount kit
Connector
Removable 6-pin terminal block for power input
Pin 1/2 for Power 1; Pin 3/4 for fault alarm; Pin 5/6 for Power 2
Removable 6-pin terminal block for DI/DO interface
Pin 1/2 for DI 0 & DI 1; Pin 3/4 for DO 0 & DO 1; Pin 5/6 for GND
Alarm
One relay output for power failure. Alarm Relay current carry ability: 1A @ 24V AC
DI and DO
2 Digital Input (DI): Level 0: -24V~2.1V (±0.1V)
Level 1: 2.1V~24V (±0.1V)
Input Load to 24V DC, 10mA max.
2 Digital Output (DO): Open collector to 24V DC, 100mA (max.)
Dimensions (W x D x H)
72 x 107 x 152mm
84 x 107 x 152mm
Weight
1684g
1533g
Power Requirements
48V DC
48~56V DC
