Planet IGS-10020 Series User Manual

User’s Manual
248
• Logging
Specify the logging operation of this port. The allowed values are:
■ Enabled: Frames received on the port are stored in the System Log.
■ Disabled: Frames received on the port are not logged.
The default value is "Disabled".
Note: The logging feature only works when the packet length is less than 1518
(without VLAN tags) and the System Log memory size and logging rate is limited.
• Shutdown
Specify the port shut down operation of this port. The allowed values are:
■ Enabled: If a frame is received on the port, the port will be disabled.
■ Disabled: Port shut down is disabled.
The default value is "Disabled".
• State
Specify the port state of this port. The allowed values are:
■ Enabled
: To reopen ports by changing the volatile port configuration of the
ACL user module.
■ Disabled: To close ports by changing the volatile port configuration of the
ACL user module.
The default value is "Enabled".
• Counter
Counts the number of frames that match this ACE.
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
: Click to refresh the page; any changes made locally will be undone.
: Click to clear the counters.
