Users Manual
313
The “>>will use the last entry of the currently displayed as a basis for the next lookup. When the end is reached the text "No
more entries" is shown in the displayed table. Use the “|<<button to start over. The page includes the following fields:
Object Description
Port
The port number for which the status applies. Click the port number to see the
status for this particular port.
VLAN ID
The VLAN ID of the entry.
MAC Address
The MAC address of the entry.
IP Address
The IP address of the entry.
Buttons
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds.
: Refreshes the displayed table starting from the "Start from MAC address" and "VLAN" input fields.
: Flushes all dynamic entries.
: Updates the table starting from the first entry in the MAC Table, i.e. the entry with the lowest VLAN ID and MAC
address.
: Updates the table, starting with the entry after the last entry currently displayed.
