User’s Manual
Priority may specify one of eight priority levels (0 through 7), as defined by IEEE
802.1D-2004. A value of 0 represents use of the default priority as defined in
IEEE 802.1D-2004.
• DSCP
DSCP value to be used to provide Diffserv node behavior for the specified
application type as defined in IETF RFC 2474. DSCP may contain one of 64
code point values (0 through 63). A value of 0 represents use of the default
DSCP value as defined in RFC 2475.
• Adding a new policy
Click to add a new policy. Specify the Application type,
Tag, VLAN ID, L2 Priority and DSCP for the new policy. Click "Save".
The number of policies supported is 32
Port Policies Configuration
Every port may advertise a unique set of network policies or different attributes for the same network policies, based on the
authenticated user identity or port configuration.
Object Description
• Port
The port number for which the configuration applies.
• Policy ID
The set of policies that shall apply for a given port. The set of policies is selected
by checkmarking the checkboxes that corresponds to the policies
Buttons
: Click to apply changes
: Click to undo any changes made locally and revert to previously saved values.
