The screen in Figure 4-16-6 appears.
Figure 4-16-6: PoE Schedule Screenshot
Please press the Add New Rule button to start setting PoE Schedule function. You have to set PoE schedule to profile and then
go back to PoE Port Configuration, and select “Schedule” mode from per port “PoE Mode” option. You can then indicate which
schedule profile could be applied to the PoE port.
The page includes the following fields:
Object Description
• Profile
Set the schedule profile mode. Possible profiles are:
Profile1
Profile2
Profile3
Profile4
• Week Day
Allows user to set week day for defining PoE function should be enabled on the day.
• Start Hour
Allows user to set what hour does PoE function enables.
• Start Min
Allows user to set what minute does PoE function enables.
• End Hour
Allows user to set what hour does PoE function disables.
• End Min
Allows user to set what minute does PoE function disables.
