User’s Manual
382
Instance Command:
Object Description
• Command
Administrative command. A port can be administratively configured to be in either
manual switch or forced switch state.
• Port
Port selection - Port0 or Port1 of the protection Group on which the command is
applied.
Instance State:
Object Description
• Protection State
ERPS state according to State Transition Tables in G.8032.
• Port 0
OK: State of East port is ok
SF: State of East port is Signal Fail
• Port 1
OK: State of West port is ok
SF: State of West port is Signal Fail
• Transmit APS
The transmitted APS according to State Transition Tables in G.8032.
• Port 0 Receive APS
The received APS on Port 0 according to State Transition Tables in G.8032.
• Port 1 Receive APS
The received APS on Port 1 according to State Transition Tables in G.8032.
• WTR Remaining
Remaining WTR timeout in milliseconds.
• RPL Un-blocked
APS is received on the working flow.
• No APS Received
RAPS PDU is not received from the other end.
• Port 0 Block Status
Block status for Port 0 (Both traffic and R-APS block status). R-APS channel is
never blocked on sub-rings without virtual channel.
• Port 1 Block Status
Block status for Port 1 (Both traffic and R-APS block status). R-APS channel is
never blocked on sub-rings without virtual channel.
• FOP Alarm
Failure of Protocol Defect(FOP) status. If FOP is detected, red LED glows; else
green LED glows.
Buttons
: Click to save changes.
Auto-refresh
: Check this box to refresh the page automatically. Automatic refresh occurs every 6 seconds.
: Click to refresh the page immediately.
: Click to undo any changes made locally and revert to previously saved values.
