User’s Manual of IGS-20040MT
different floor-to-floor dimensions. An altitude = 0.0 is meaningful even outside a
building, and represents ground level at the given latitude and longitude. Inside a
building, 0.0 represents the floor level associated with ground level at the main
entrance.
 Map Datum
The Map Datum used for the coordinates given in this Option
 WGS84: (Geographical 3D) - World Geodesic System 1984, CRS Code
4327, Prime Meridian Name: Greenwich.
 NAD83/NAVD88: North American Datum 1983, CRS Code 4269, Prime
Meridian Name: Greenwich; The associated vertical datum is the North
American Vertical Datum of 1988 (NAVD88). This datum pair is to be used
when referencing locations on land, not near tidal water (which would use
Datum = NAD83/MLLW).
 NAD83/MLLW: North American Datum 1983, CRS Code 4269, Prime
Meridian Name: Greenwich; The associated vertical datum is Mean Lower
Low Water (MLLW). This datum pair is to be used when referencing locations
on water/sea/ocean.
Civic Address Location
IETF Geopriv Civic Address based Location Configuration Information (Civic Address LCI).
Object Description
The tw
o-letter ISO 3166 country code in capital ASCII letters - Example: DK, DE
or US.
 Country code
National subd
ivisions (state, canton, region, province, prefecture).
 State
Count
y, parish, gun (Japan), district.
 County
City,
township, shi (Japan) - Example: Copenhagen
 City
Cit
y division, borough, city district, ward, chou (Japan)
 City district
 Block (Neighborhood)
Neighborhood, block
Street - Examp
le: Poppelvej
 Street
Leading
street direction - Example: N
 Leading street
direction
Trailing street s
uffix - Example: SW
 Trailing street suffix
Street suf
fix - Example: Ave, Platz
 Street suffix
House numbe
r - Example: 21
 House no.
 House no. suffix
House number suffix - Example: A, 1/2
308

Planet IGS-20040MT Specifications

General

Switch type	Managed
Switch layer	L2+
Traffic classification	Yes
Console port	RJ-45
Fiber optic connector	MiniGBIC
SFP module slots quantity	4
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4095
Networking standards	IEEE 1588v2, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ag, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ah, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Stackable	-
Certification	FCC, CE
Product color	Blue, White
Housing material	Aluminum
International Protection (IP) code	IP30
Fiber ethernet cabling technology	100BASE-FX, 1000BASE‑BX, 1000BASE‑LX, 1000BASE‑SX
Throughput	29.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Number of IP interfaces	8
Power consumption (max)	17 W
Power consumption (typical)	8 W
Heat dissipation	27 BTU/h
Storage temperature (T-T)	-40 - 85 °C
Operating temperature (T-T)	-40 - 75 °C
Operating relative humidity (H-H)	5 - 95 %
Supported network protocols	IPv4 / IPv6
Authentication	MAC-based authentication, Port-based authentication
Security algorithms	802.1x RADIUS, SSH, SSL/TLS
Number of multicast groups filtered	255
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	107.3 mm
Width	76.8 mm
Height	152 mm
Weight	1043 g
