ENGINE
2.22
Engine Assembly - Continued
19. Insert the vibration dampener into the cooling
fins between the intake ports. Reinstall the
two fan shrouds making sure that they
interlock before fastening tightly.
20. Using a new o-ring, reinstall the oil pump.
21. Install each carburetor and torque the
carburetor mounting clamps Reinstall oil lines
on the oil pump.
Oil Pump Mounting Screw Torque:
48 - 72 in.lbs. (5.5 - 8.3 Nm)
