d. Pull the EV cable taunt to bring the valves to the
full open position and remove the exhaust valve
assembly
3!
from the engine.
NOTICE
Removal of the lower steering post bushing fasteners
and bushings is required for the exhaust valve
assembly to be removed.
e. With the exhaust valve assembly removed and
still connected to the actuator, wrap exhaust valve
assembly in shop towel and place in the nose of
the snowmobile.
35.Disconnect the water temp sensor
3@
and DET sensor
3#
from the wiring harness.
NOTICE
Remove any cable ties but note locations for
installation.
36.Remove the stator connector
3$
from the wiring
harness.
37.Remove the cable ties
3%
from the wire supports.
NOTICE
Do not remove the cable ties securing the support to
the coolant hose.
