▌ CREATING A MIDI CC OUTPUT STEP
1. Ensure the Cong > MIDI settings are set to send MIDI.
2. Press [Pattern] to select the Pattern Mode page.
3. Select the target step to edit. Use [Up], [Down] or Turn (Jog) to scroll
top to bottom. Press [Left], [Right] to select a track. Example Row 1 of
Track 1. The step should be highlighted with the green bounding box.
4. Press [Rec] to switch to recording mode. The step bounding box will
turn red and allow editing of the step.
5. Hold [Instrument] + Turn (Jog) to select a MIDI instrument from the 51
to 61 part of the list. Each one will represent a MIDI channel where the
step messages will be transmitted. The Instrument will be indicated with
an ‘M’ in the instrument slot for the step. Example M01.
6. Hold [FX1] or [FX2] + Turn (Jog) to set a CC for the step. This will be
one of the 6 options a-f. The selected option will show as a lower case
letter in the step FX slot. Example: a MIDI CC A.
7. With the FX selected, Turn (Jog) to set it’s CC value. A series of steps
could for example be lled with a ramp up of values. This can be
changed later. Example: Set to 50.
8. Press [Instrument Parameters] to select the MIDI conguration.
9. Select a CC Slot that matches the FX selection - Example, Press [CC
A], 3
rd
Screen button. Any other CC A - CC F can be selected to match
up the the FX setting.
10. Press [Up] or [Down] or Turn (Jog) to scroll the CC parameter lists.
Highlight with the bounding box the CC number to assign. This would
typically be based on the MIDI CC conguration on a receiving device.
Example: CC 74 is Filter Cutoff on Elektron’s Digitakt.
11. In this example, CC Number 74 will transmit a CC value of 50 over MIDI
Channel 1 when the selected step is triggered.
The MIDI CC outputs in the Instrument Parameters list follows MIDI standards. Many of the CC’s
are undened. Check the MIDI conguration for any connected devices to know what CC will affect
which parameter. This list is available for each of the 6 CC Assignments A - F. Also the Program
Change 128, Channel Aftertouch 129 and Polyphonic Aftertouch 130 can also be congured here.
CC # Function CC # Function CC # Function CC # Function
0
Bank (MSB)
32
Bank (LSB)
64
Sustain
96
Data Increment +
1
Mod Wheel (MSB)
33
Mod Wheel (LSB)
65
Portamento
97
Data decrement -
2
Breath Control (MSB)
34
Breath Control (LSB)
66
Sostenuto
98
NRPN LSB
3 35 67
Soft Pedal
99
NRPN MSB
4
Foot Pedal (MSB)
36
Foot Pedal (LSB)
68
Legato
100
RPN LSB
5
Glide (MSB)
Portamento Rate
37
Glide (LSB)
Portamento Rate
69
Hold 2
101
RPN MSB
6
Data Entry (MSB)
38
Data Entry (LSB)
70 102
7
Channel Volume (MSB)
39
Channel Volume (LSB)
71 103
8
L/R Balance (MSB)
40
L/R Balance (LSB)
72 104
9 41 73 105
10
Pan (MSB)
42
Pan (LSB)
74 106
11
Expression Pedal (MSB)
43
Expression Pedal (LSB)
75 107
12 44 76 108
13 45 77 109
14 46 78 110
15 47 79 111
16 48 80 112
17 49 81 113
18 50 82 114
19 51 83 115
20 52 84
Portamento Amount
116
21 53 85 117
22 54 86 118
23 55 87 119
24 56 88
High Denition Velocity
120
All sound off
25 57 89 121
Reset all
26 58 90 122
Local On / Off
27 59 91 123
All notes off
28 60 92 124
29 61 93 125
30 62 94 126
31 63 95 127
