Audio
8
Audio
8
Global Mixer - Page 3
The Global Mixer is the third page in the master pages and contains the line
in level and line in delay / reverb send levels for the pass through. Also the
overall master delay, reverb level and dry / wet mix. These can all be muted
and all soloed, with the exception of the line delay and reverb which can
only be muted / unmuted.
Mute Button Behaviour.
In the master section mute is applied when the button is released after being pressed.This is different to muting in
the Pattern section where mutes are applied immediately that the button is pressed.
Actual stereo level.
Centre + right bar
Global Mixer
Page 3 of 3
Line Input Passthrough
Line In level, Delay and
Reverb Send amounts.
Level
Left bar is the level setting
also displayed in the label
area. Also controllable by
MIDI CC79-82
-4.50 dB
Mute
0.00 dB
Mute
1.80 dB
Mute
0.00 dB
Unmute
0.00 dB
Unmute
0.00 dB
Unmute
Reverb Line RvbDry Mix Line InDelay Line Dly
Global Mixer 3/3 0m:00s P1.008
Function
Command
Adjust Level Hold Option Screen Button 1-6 + Turn (Jog) or Press [Up] or [Down]
Mute Option Press Option Screen Button 1-6 to toggle Mute / Unmute
Unmute Track Press Option Screen Button 1-6 to toggle Mute / Unmute
Solo Option Hold [Shift] + Press Option Screen Button 1-4 to toggle Solo on/off
Delay
Displays and adjusts amount of
master (all tracks) delay amount.
Reverb
Displays and adjusts amount of
master (all tracks) reverb amount.
Dry / Wet
Displays and adjusts mix level of
the delay and reverb and the
unaffected dry signal.
8.2 Audio Sources
There are a number of sources where Tracker can access audio. Some of
which are ‘live’ sources and can easily be sampled. Others manually
managed or rendered within the device.
SD Card Samples
Audio samples
Radio
Sample from FM Radio
Line Input
External audio gear connection.
Line Input
3.5mm Input jack which allows Stereo (TRS) and Mono (TS) audio inputs.
Stereo signals are converted to mono when recorded and the L & R channels
can also be selected individually.
Render
A feature which is available with the internal functions is render. This bounces or
exports an audio le based on the selected pattern / tracks which can then be
made immediately available as a sample or to use from the instrument list.
Mic Input
3.5mm Microphone Input jack which allows Stereo (TRS) and Mono (TS) audio
inputs. Stereo signals are converted to mono when recorded. This does not
supply 48V phantom power so typically use a dynamic microphone.
FM Radio
Tracker has an inbuilt FM radio. Reception can be improved by connecting an
arial or cable into the output connection. The reception region can be set in the
radio function. Radio can be recorded and sampled directly within Tracker.
SD Card
Audio samples are stored on the SD Card. These can be sampled and stored
from within Tracker but also can be manually transferred onto the SD card from
and external source using a PC or Mac.
Tracker is supplied with a 3.5mm Stereo Male Jack to 2 x 6.3mm Mono Female Socket adapter
to allow interfacing with external gear and using the more common 6.3mm mono cables.
Microphone Input
External microphone.
Render
Bounce Internal Audio.
5
1
1
4
5
4
2
2
3
3
Folder
Out Line In Mic MIDI Out MIDI In Micro SD
USB Power
