8.7 Sampling
Everyone will develop a personal workow for sampling and the process
may differ due to the source to be recorded. Polyend Tracker allows approx
45 seconds of recorded audio time per sample and each project has a total
of 133 seconds of mono sample time.
The main page used at the sampling stage is the [Sample Recorder]. Here
the parameter settings can adjusted pre sampling. The selected source will
determine the available options. Controlling the start and stop recording
process is triggered within this page.
Source
Line In
Gain
5
Monitor
On
RecordLevel
On
Off
Line In
Radio
Mic LG
Mic HG
Sample Recorder 0m:00s P1.008
Monitor.
Will allow the audio source to
be previewed at the output.
Source
Select the input to record
in the sampler.
Gain
Boosts the signal
level
Recording
Starts Recording [Record].
Also button becomes [Stop] while recording in is in progress.
Also can be directly controlled with the [Rec] Button.
Level
Visual indicator of source
volume level.
8.6 Recording Audio Workow
Sampling in Tracker takes place in the ‘Sample Recorder’ page. This is the
rst step in the process and is followed by editing the audio captured.
Sampling in this page can be from the Line In, Radio or Mic audio sources.
Connect an external synth or
audio source or microphone
or tune the radio to a channel.
Open the [Sample Recorder]
page to set up for sampling.
Select the source to record from.
Options are; Line In, Mic or Radio.
Save Only to the SD
Card.
Save to the SD Card
and also load into the
instrument list.
Program using the
instrument into a pattern.
Adjust gain to set to a
suitable level.
Play the connected
audio source.
Press [Record] to capture
the audio sample.
[Stop] sampling.
Max 45 sec audio sample.
Save the sample. Trim the start and end
of the sample to select
the area to save.
Connect Gear Sample Recorder
Gain
Play
Save
Record
Crop
Stop
Select Source
Save to SD
Save & Load
Pattern
E
S
To Next Page
