7088-8000
-149
Liner Material
To select the liner material:
1. From the
LINER
options group, click on the down arrow to the right of the
MATERIAL
text box.
The following selections are displayed:
!
NONE
(no liner)
!
TAR EPOXY
!
RUBBER
!
MORTAR
!
POLYPROPYLENE
!
POLYSTYROL
!
POLYSTYRENE
!
POLYESTER
!
POLYETHYLENE
!
EBONITE
!
TEFLON
!
OTHER
2. Click on the desired selection.
IMPORTANT:
The selection
OTHER
denotes any material not listed. If
OTHER
is
selected, the liner sound speed and liner inside roughness must be entered.
Liner Sound Speed
Liner sound speed is configurable only if
OTHER
was selected as the liner material. If
OTHER
was not selected, the liner sound speed is available for viewing only.
To set the liner sound speed:
1. From the
LINER
options group, click on the
SOUND SPEED
text box.
2. Enter the liner sound speed.
Liner Inside Roughness
Liner inside roughness is configurable only if
OTHER
was selected as the liner material.
Data on this parameter is available from the Cameron Hydraulic Data Book published by
Ingersoll-Rand. If
OTHER
was not selected, the liner inside roughness is available for
viewing only.
1. From the
LINER
options group, click on the
ROUGHNESS
text box.
2. Enter the liner roughness.
