7088-8000
-28
3.3.2 SCROLLING THROUGH PRIMARY DISPLAYS, SETUP MENUS, AND
DIAGNOSTIC MENUS
The user can move from one Primary Display, setup menu, or diagnostic menu to another
within the same sub-menu by scrolling. Pressing the
DOWN
ARROW
key displays the next
display or menu, while pressing the
UP ARROW
key displays the previous one.
3.4 Entering Data in the Setup Menus
This section provides basic procedures for entering configuration data which is done in the
setup menus. Some setup menus allow a numeric value to be entered, while others offer
non-numeric selections. Refer to Section 3.6 for more detailed information on specific
menus.
The following is an example of a setup menu which requires a numeric entry:
PIPE ID
4.02 INCHES
In a non-numeric selection menu, an asterisk is displayed to the left of the selection
currently entered in the flowmeter. The following is an example of a non-numeric selection
setup menu:
Pipe Material
*CARBON STEEL
To use the setup menus to configure the flowmeter:
1. Access the setup menus one at a time using the direct menu access method
(Section 3.2) and/or the scrolling method (Section 3.3).
IMPORTANT:
As a minimal requirement, the setup menus that are listed in the Quick
Setup procedure (Section 3.5) must be configured.
2. If the setup menu requires a numeric entry, use the numeric keys and press
ENTER
when complete. (If an error is made while entering a numeric value, use the
ERASE
key to delete it.)
3. If the setup menu offers a non-numeric selection:
!
Press
ENTER
.
The asterisk changes to a flashing cursor.
!
Use the arrow keys to scroll through the available selections.
!
When the cursor is to the left of the desired selection, press
ENTER
to select it.
