7088-8000
-37
Transducer Mounting (Menu 24)
This menu is used to select one of the following
transducer mounting methods:
!
V
!
W
!
Z
Refer to Section 4.4 for more information on the
transducer mounting methods.
Transducer Spacing (Menu 25)
This view-only menu indicates the required spacing
between the transducers. This spacing is calculated by
the flowmeter once the parameters listed in the Quick
Setup procedure have been entered. Refer to
Section 4.2 for more information on transducer
spacing.
3.6.6 FLOW SETUP MENUS
The
FLOW
sub-menu contains the setup menus related
to flow.
Flow Units (Menu 30)
This menu is used to select the flow rate units.
Volumetric units are displayed first, followed by the
associated time (per) units.
To select the flow rate units:
1. Select one of the following volumetric units:
!
GALLONS
!
LITERS
!
MGAL (
million gallons
)
!
CUBIC FT
!
CUBIC METERS
!
ACRE FT
!
OIL BARRELS
!
LIQUOR BARRELS
!
FEET
!
METERS
Transducer Mount
*V Mt. Z Mt. W Mt.
Transducer Spacing
5.93 Inches
Flow Units
*Gallons
