7088-8000
-52
8. Press the
DOWN
ARROW
key.
The Alarm Off Condition Value screen is
displayed:
9. Enter the value for the alarm OFF condition and
press
ENTER
.
10. Repeat steps 1 through 9 for all alarms that are to
be programmed.
View Alarms (Menu 72)
This menu is used to display the current ON and OFF
conditions of the alarms.
To view the current alarm conditions:
1. Access Menu 72:
2. Select an alarm. (The alarms are displayed as
!
1
through
!
4
.)
The ON and OFF conditions for the selected alarm
are displayed:
3.6.12 DATA LOG SETUP MENUS
The
DATA LOG
sub-menu contains the setup menus
for the data logger.
Data Log Setup (Menu 80)
This menu is used to set up the data logger. The data
logger provides the ability of continuously recording
flow data at preset intervals for long time periods.
There are approximately 65,000 data points available
to the data logger memory. This allows considerable
data to be collected. For instance, collecting at
60-second intervals, the flowmeter could store data for
approximately 44 days. The data logger can be started
and stopped manually or can be programmed to run
automatically for a future start and stop time.
Once a data log file is complete, it is stored in the
flowmeter for future retrieval. The file is automatically
assigned a unique file number, allowing additional data
logs to be recorded and retrieved. (The file number is
based on the record date plus a sequence number.) The
Off Cond. Value
24.00 Gal/S
Show Alarm #
!
!!
!
1
!
!!
!
2
!
!!
!
3
!
!!
!
4
On = Flow <16
Off = Flow >24
Log Menu
!
!!
!
Start
!
!!
!
Auto
To Next Page
