7088-8000
-148
Pipe Sound Speed
Pipe sound speed is configurable only if
OTHER
was selected as the pipe material. If
OTHER
was not selected, the pipe sound speed is available for viewing only.
To set the pipe sound speed:
1. From the
PIPE
options group, click on the
SOUND SPEED
text box.
2. Enter the pipe sound speed.
Pipe Inside Roughness
Pipe inside roughness is configurable only if
OTHER
was selected as the pipe material.
Data on this parameter is available from the Cameron Hydraulic Data Book published by
Ingersoll-Rand. If
OTHER
was not selected, the pipe inside roughness is available for
viewing only.
1. From the
PIPE
options group, click on the
ROUGHNESS
text box.
2. Enter the pipe roughness.
NOTE:
The number entered for pipe roughness is not important on lined pipes. In this
case, the liner inside roughness should be entered (Section F.4.2)
F.4.2 LINER OPTION GROUP
The
LINER
option group is accessed by clicking on
LINER
in the Options Column. This
group contains the options related to the liner including liner material and liner thickness.
Liner Thickness
To set the liner thickness:
1. From the
LINER
options group, click on the
THICKNESS
text box.
2. Enter the liner thickness.
To Next Page
