3.6.8 OPTIONS SETUP MENUS
The
OPTIONS
sub-menu contains the setup menus for
several miscellaneous functions, such as selection of
English or metric flow units, changing the system and
scale factor passwords, and RS232 settings.
Measurement Units (Menu 42)
This menu is used to select one of the following types
of measurement units for the flowmeter:
!
ENGLISH
!
METRIC
If
ENGLISH
is selected, pipe dimensions are displayed
in inches and velocities are displayed in feet per
second (FPS), where appropriate. If
METRIC
is
selected, the measurements are displayed in
millimeters (mm) or meters per second (MPS).
Site Parameters (Menu 43)
This menu saves the parameters for the pipe, liner,
fluid, transducer, and flow setup menus to allow these
parameters to be recalled later for a specific
measurement site. Up to 16 different sites are
available, and are numbered from 1 through 16. The
site number is displayed in Menu 43 in the lower left
corner of the screen and is followed by a colon (:). (For
example 1: represents site number 1.)
As the setup parameters are entered in their respective
menus during normal configuration, the same
parameters are saved simultaneously in the Site
Parameters function. These site parameters are stored
in whichever site is currently active (in whichever site
has the asterisk displayed in Menu 43).
Access a different site to automatically re-enter that
site’s stored parameters into the flowmeter for
measuring flow. To access a different site, press
ENTER
, scroll to the desired site, and press
ENTER
again.
Measurement Units
*English Metric
Site Parameters
1:3.507 In, PVC
To Next Page
