7088-8000
-44
NOTE:
To avoid entering parameters “on top of” a
previously stored set and losing the old data,
ensure that the desired site is active in Menu
43 before entering the new set of parameters.
RS232 Configuration (Menu 46)
This menu is used to configure the flowmeter’s RS232
port. The RS232 port allows the flowmeter to connect
to an IBM-compatible PC using the PolyLink or
TimeGATE
™
data link utilities (Appendices A and F).
These utilities provide features such as data log file
downloads, remote configuration and monitoring, and
software upgrades.
To configure the RS232 port:
1. Access Menu 46:
2. Select one of the following modes:
!
TIMEGATE
!
POLYLINK
3. Press the
DOWN
ARROW
key to display the baud
rate selections:
The baud rate is the only RS232 parameter that can
be selected. Parity is preset at none, the character
size is preset at 8, and the stop bits are preset at 1.
(All selections are N,8,1.)
Select one of the following baud rates:
!
1200
!
2400
!
4800
!
9600
!
19200
Change System Password (Menu 47)
This menu is used to change the system password. The
system password is designed to protect the flowmeter’s
configuration parameters from unauthorized or
accidental changes. The system password may be
enabled or disabled. The flowmeter ships from the
factory with the system password disabled.
RS232 Mode
*TimeGate PolyLink
RS232 Config
9600,N,8,1
