Appendix C
A-90
10. To exit PolyLink from a PC, press
F10
to “back out” of the program one screen at a
time until the C: prompt is displayed.
A.2.2 RUNNING POLYLINK FROM A DDF3088
To run PolyLink from a DDF3088, the DDF3088 must have software version 2.2 or higher
installed. Due to the limited size of the DDF3088 display, the PolyLink screens are slightly
different than those on a PC. In addition, the PolyLink options on a DDF3088 may require
a different function key. The function key options on a DDF3088 are listed above the
associated function key.
CAUTION:
Before running PolyLink from a DDF3088, note all setup parameters
entered in the DDF3088 flow program. When PolyLink is run from a
DDF3088, most setup parameters are erased, including those for
Battery Setup. After exiting PolyLink, the DDF3088 flow program
restarts, requesting new Battery Setup parameters first.
To run PolyLink from a DDF3088:
1. Ensure that both the DDF3088 and the flowmeter are turned on and that the flow
program is running on the flowmeter.
2. Screw the round connector of the optional RS232 Com Cable into the RS232 port of
the DDF3088. (The RS232 port is located on the top left of the instrument farthest from
the Polysonics logo [Figure A-2].)
Figure A-2 Connecting the RS232 Com Cable to the DDF3088
