7088-8000
-56
Delta Time/Fluid Sound Speed (Menu 91)
This menu displays the value for DeltaT and the fluid
sound speed as measured by the flowmeter. DeltaT is
the difference between the upstream and downstream
travel time, expressed in nanoseconds.
Reynolds #/Profile Factor (Menu 92)
This view-only menu displays the Reynolds number
and flow profile factor currently being used by the
flowmeter. The flow profile factor is calculated by the
flowmeter and is used to determine the effect of the
flow profile on mean measured fluid velocity.
Current Loop Output (Menu 93)
This view-only menu displays the value of the current
in milliamperes that the flowmeter is presently
providing to the current loop output.
Software/Firmware Rev. Level (Menu 94)
This view-only menu displays the version of software
(
SOFT VERS.
) and firmware (
FPGA VERS.
) that are
installed in the flowmeter.
NOTE:
Refer to Chapter 1 for information on
software upgrades.
3.6.14 PRINT SETUP AND PRINT COMMANDS
The optional printer can be configured in the
PRINT
sub-menu in Menu 96. In addition, certain data may be
printed by pressing
MENU
plus 97, 98, or 99 from any
screen. (There are no specific screens displayed on the
flowmeter for these three print commands.)
Print Log Setup (Menu 96)
This menu is used to set up the optional printer. The
printer can be configured to print out flow data at a
preset interval and/or whenever an alarm is activated.
The flow data that is printed includes the data from all
enabled totalizers.
DeltaT = 0.00 ns
SSpeed = 4863.33 FPS
Reynolds= 0
Factor =0.750000
Current Loop
Output = 4.57 mA
Soft Vers. = 1.00
FPGA Vers. = A0
