EGM-5 Operation Manual V. 1.04 103 support@ppsystems.com
+<CR>
N,12.1324, 6.6143, 0.4765, 0.0000, 0.0000<CR>
In this example,
External Voltage=12.1324, System Voltage=6.6143, Flow Sensor
Voltage=0.4765, AUX1 Voltage=0.0000 and O
2
Sensor Voltage=0.0000.
P,x
Character
with
Parameters
“P” Command (Process Modes)
This command is used to Select and Control a process.
The x parameter determines which Process action will be performed.
Description of x:
1 = Stop process (returns to standard Measure mode)
2 = Stop process and Save Last Measurement
3 = Save Last Measurement
4 = Fan on High Speed
5 = Fan on High Speed and stop Zeros
6 = Fan on low speed
7 = Fan on low speed and start Zeros
20 = Start the SRC process or Restart if already running
30 = Start the Injection process or Restart if already running
40 = Start the Static process or Restart if already running
50 = Start the CPY process or Restart if already running
60 = Start the Custom process or Restart if already running
Example:
Sent from Host: P,20<CR> (Start SRC process)
Received from EGM-5:
+<CR>
In this example the SRC process is started.
S,x,v
Character
with
Parameters
“S” Command (Save Setting)
This command sets a parameter in EEPROM (non-volatile memory). The x
parameter specifies a particular setting, and the v parameter is the desired value
of the particular setting, which will be saved in the EEPROM. A ‘G’ command is
returned to confirm that the request was accepted. See Get/Set Parameter Values
Table on page 106.
Example:
