Before using PrismJET 54 Gen2 OPERATION MANUAL
112 3.6 Adjust Print
4. Check the print results on both sides and center of the media and select the number that looks most
aligned between 1 and 7.
• “6” is selected in the following pattern.
• “4” represents the current setting value.
• When the line is aligned, the bold line on its left side does not have a white vertical line in the
middle.
• “PatternA: 4” is displayed on the operation panel.
5. Press the [+] key or [–] key to enter the number that you selected in Step 4.
• When you press the [Cancel] key, the input operation is not executed and “Adj.9: Fine Ptn. ALL”
is displayed on the operation panel.
Not adequate Adequate
Not adequate
To Next Page
