PrismJET 54 Gen2 OPERATION MANUAL Panel setup menu
5.1 Setup menu 157
NOTE
• The settings here are the same as 5.1.1.1.9 Media thickness menu.
Auto Adjust Print Menu
Perform the automatic adjustment using the embedded color sensor.
Standard Adjust Print Menu
Adjusts only the print mode in the user type setting which is currently set.
Setup item Setting Description
Adj. Print1: Auto ALL Perform automatic adjustment for all patterns (A to F) using
the color sensor.
3.6.2 Auto Adjust Print
Standard Perform automatic adjustment for the currently selected print
mode using the color sensor (calibrate the same print mode as
"Standard Adjust Print Menu").
3.6.2 Auto Adjust Print
Pattern A to F Choose the adjustment pattern between A and F for automatic
adjustment.
3.6.2 Auto Adjust Print
—
• [Cancel] key: cancels the setting and shifts to the previous
menu.
5.1.1.1.3 Adjust Print menu
Setup item Setting Description
Adj. Print2: Standard Confirm Ptn. Print the test pattern for the alignment.
Check before adjusting.
3.6.3.1 Standard Confirmation Pattern
Rough Pattern Perform this adjustment when the misalignment is large.
Print adjustment patterns and enter the set values.
3.6.3.2 Standard Rough Adjustment Pattern
Fine Pattern Perform this adjustment when the misalignment is small.
Print adjustment patterns and enter the set values.
3.6.3.3 Standard Micro Adjustment Pattern
—
• [Cancel] key: cancels the setting and shifts to the previous
menu.
5.1.1.1.3 Adjust Print menu
