Panel setup menu PrismJET 54 Gen2 OPERATION MANUAL
158 5.1 Setup menu
Custom Adjust Print Menu
Perform adjustment for all patterns (A to F).
All print modes will be adjusted.
Setup item Setting Description
Adj. Print3 : Custom Confirm Ptn. The test patterns of A to F will be printed for Adjust print.
Check before adjusting.
3.6.4.1 Custom Confirmation Pattern
Rough Ptn. ALL Perform this when the degree of misalignment is large.
Print Adjust patterns A to F and enter the set values.
3.6.4.2.1 Rough Pattern ALL
Rough Pattern A to F When the degree of misalign is big, print out an adjust pattern
selected from A to F and enter the value.
3.6.4.2.2 Rough Pattern A to F
Fine Ptn. ALL Perform this when the degree of misalignment is small.
Print Adjust patterns A to F and enter the set values.
3.6.4.3.1 Fine Pattern ALL
Fine Pattern A to F When the degree of misalign is small, print out an adjust
pattern selected from A to F and enter the value.
3.6.4.3.2 Fine Pattern A to F
—
• [Cancel] key: shifts to the previous menu.
5.1.1.1.3 Adjust Print menu
