PrismJET 54 Gen2 OPERATION MANUAL Maintenance
6.2 Cleaning the printer 271
4. Open the maintenance cover L.
5. Move the print head section by hand to where the circumference of the color sensor is visible.
CAUTION
• Do not press the Print head section strongly. Doing so may cause damage or poor
print results.
No. Name
1 Maintenance cover L
No. Name
1 Print head section
2 Color sensor
1
2
