PrismJET 54 Gen2 OPERATION MANUAL Before using
3.6 Adjust Print 107
3. Press the [Enter] key on Operation panel.
• “Warming Up Skip ->E” is displayed on Operation panel.
CAUTION
• While “Warming Up” is displayed, do not touch Platen and Media guide.
They become very hot and you could burn yourself.
NOTE
• You can start printing during warming up.
4.4.8 Start Printing during Warm up
• A rough adjust print pattern is printed.
(Starts printing after warming up is complete.)
• For the Adjust print pattern, the same patterns will be printed repeatedly on both sides and center
of the media.
1234567891011
Bi dir
Low H.Height
normal speed
large drop family
Pattern name
Print information
