PRISMJET 54 Gen2 - Page 98

Before using PrismJET 54 Gen2 OPERATION MANUAL
108 3.6 Adjust Print
4. Check the print results on both sides and center of the media and select the number that looks most
aligned between 1 and 11.
• “9” is selected in the next printing sample.
NOTE
• “6” represents the current setting value.
• When the line is aligned, the bold line on its left side does not have a white vertical line.
• “PatternA: 6” is displayed on Operation panel.
5. Press the [+] key or [-] key on Operation panel to enter the number that you selected in Step 4.
NOTE
• When you press the [Cancel] key on Operation panel, the display returns to “Adj.3:
RoughPatternA”.
8910
Not adequate Adequate
Not adequate
