4 Installation and assembly
n User qualification, mechanical installation: trained and qualified
personnel
Ä Chapter 2.4 ‘User qualification’ on page 14
n User qualification, electrical installation: Electrical technician
Ä Chapter 2.4 ‘User qualification’ on page 14
4.1 Ambient Conditions for Operation
Ambient conditions for operation
n Temperature: 0 °C ... + 50 °C
n Air humidity: < 90 % relative air humidity (non-condensing)
The controller may not be installed in hazardous environments or
in places where it could be exposed to spraying water or chemi‐
cals. The installation site must be dry, well ventilated and free of
corrosive gases.
Select an installation site without vibrations, on a suitable base sur‐
face without deformations.
Protect the controller from rain, frost and direct sunlight.
4.2 Scope of Delivery
The following components are included as standard with a con‐
troller.
Description Quantity
Assembled device 1
Cable connection set DMTa/DXMa (metr.) 1
Operating instructions 1
4.3 Installation
n User qualification, mechanical installation: trained and qualified
personnel
Ä Chapter 2.4 ‘User qualification’ on page 14
n User qualification, electrical installation: Electrical technician
Ä Chapter 2.4 ‘User qualification’ on page 14
Remember to switch off the controller before
undertaking installation and electrical wiring.
The prerequisite for protection class IP65 is that
the terminal cover and transparent cover of the
controller are sealed, that the cable openings have
been selected in accordance with the cable diame‐
ters and are correctly sealed.
Installation and assembly
16
