ProMinent Splash Control Pro 2 - P.I.D. Metering Mode

A3151
V.
IV.
III.
II.
VI.
VII.
VIII.
I.
Fig. 100: Metering mode - ‘Threshold value’
I. Measure
II. Time
III. Time
IV. Falling action
V. Rising action
VI. Capacity
VII. Threshold
VIII. Threshold
8.2.5 ‘P.I.D.’ metering mode
A3152
E01 pH value
Active threshold
Maximum time
Basic load
P.I.D. mode
Proportional
Setpoint
Setpoint and control settings
Derivative
Integral
Dead zone
Fig. 101: ‘P.I.D.’ metering mode
Setting measuring and control parameters
