6.1 Displaying details on the “Small x6” channels
I.
IV.
III.
II.
1716
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
23
22
2120
19
18
A3033
Fig. 38: Details of the measuring channel illustrated by pH
Main group Subgroup Function
I: Alarm notifications
1 Technical alarm
2 Measured value too low
3 Measured value too high
4 Disabled setting
II: Measured value and units
5 Measured value lower than can be displayed on the scale.
Details of the measuring channel
