Fig. 40: Details of the flow channel
Main group Subgroup Function
I: Alarm notifications
1 Technical alarm
2 Measured value too low
3 Measured value too high
4 Check the flow or flow volume.
5 Disabled setting
II: Measured value and units
6 Measured value lower than can be displayed on the scale.
7 Measured value higher than can be displayed on the scale.
8 Measured value cannot be displayed.
9 Measured value cannot be measured. Technical alarm
III: Alarm status
10 Threshold low / threshold high
Details of the flow channel
Operating concept and operation
40
