Modbus reg‐
ister
Number of
registers
Name Access Format Description
41077 1 Zustand_HO2 r BOOL 0 = Outside of the range / 1 =
Within the range (schedule)
41078 1 Zustand_HO3 r BOOL 0 = Outside of the range / 1 =
Within the range (schedule)
41079 1 Zustand_HO4 r BOOL 0 = Outside of the range / 1 =
Within the range (schedule)
41080 1 Zustand_HO5 r BOOL 0 = Outside of the range / 1 =
Within the range (schedule)
41081 1 Zustand_HO6 r BOOL 0 = Outside of the range / 1 =
Within the range (schedule)
41082 1 Zustand_HO7 r BOOL 0 = Outside of the range / 1 =
Within the range (schedule)
41083 1 Zustand_HO8 r BOOL 0 = Outside of the range / 1 =
Within the range (schedule)
41092 2 Local time stamp r DWORD Time since 1 January 1970
00h00 [s]
Values and statuses
41101 1 geräte_zustand rw WORD Bit 0: Device running Bit 1:
Timer running Bit 2: Device
layer formation Bit 3: Device
stopped by timer
41201 2 param_E1_state rw DWORD Compare with Param State
41203 2 param_E1_Mess‐
wert_Messung
r REAL Measured value [unit of
measure]
41205 2 param_E1_Kon‐
trolle_w
rw REAL Control setpoint [unit of
measure]
41207 2 param_E1_dosage
_u
r REAL Metering control [1/1]
41209 2 param_E1_alarm_
hoch
rw REAL High alarm value [unit of
measure]
41211 2 param_E1_alarm_
niedrig
rw REAL Low alarm value [unit of
measure]
41251 2 param_E2_state rw DWORD Compare with Param State
41253 2 param_E2_measur
e_value
r REAL Measured value [unit of
measure]
41255 2 param_E2_Kon‐
trolle_w
rw REAL Control setpoint [unit of
measure]
41257 2 param_E2_dosage
_u
r REAL Metering control [1/1]
41259 2 param_E2_alarm_
hoch
rw REAL High alarm value [unit of
measure]
41251 2 param_E2_alarm_
niedrig
rw REAL Low alarm value [unit of
measure]
41301 2 param_E3_state rw DWORD Compare with Param State
41303 2 param_E3_measur
e_value
r REAL Measured value [unit of
measure]
Communication programming instructions
