Modbus reg‐
ister
Number of
registers
Name Access Format Description
42501 130 param_E3 r STRUC‐
TURE
E3 channels statuses and
value
42701 130 param_E4 r STRUC‐
TURE
E4 channels statuses and
value
42901 130 param_E5 r STRUC‐
TURE
E5 channel statuses and
value
43101 130 param_E6 r STRUC‐
TURE
E6 channels statuses and
value
43301 130 param_E7 r STRUC‐
TURE
E7 channels statuses and
value
43501 130 param_E8 r STRUC‐
TURE
E8 channels statuses and
value
Capteur
45301 36 sensor_PI1 r STRUC‐
TURE
PI1 sensor statuses and
values
45351 36 sensor_PI2 r STRUC‐
TURE
PI2 sensor statuses and
values
45401 36 aufnehmer_AI1 r STRUC‐
TURE
AI1 sensor statuses and
values
45451 36 Fühler_AI2 r STRUC‐
TURE
AI2 sensor statuses and
values
45501 36 sensor_AI3 r STRUC‐
TURE
AI3 sensor statuses and
values
45551 36 aufnehmer_AI4 r STRUC‐
TURE
AI4 sensor statuses and
values
45601 36 sensor_MI1 r STRUC‐
TURE
MI1 sensor statuses and
values
45651 36 sensor_MI2 r STRUC‐
TURE
MI2 sensor statuses and
values
45701 36 aufnehmer_KI1 r STRUC‐
TURE
DIx sensor statuses and
values
45751 36 aufnehmer_KI2 r STRUC‐
TURE
DIx sensor statuses and
values
Contacts
46051 12 Schalter_DI1 r STRUC‐
TURE
Contact status of DI1
46076 12 Schalter_DI2 r STRUC‐
TURE
Contact status of DI2
46101 12 Schalter_DI3 r STRUC‐
TURE
Contact status of DI3
46126 12 Schalter_DI4 r STRUC‐
TURE
Contact status of DI4
Relay
46301 58 Relais_PO1 r STRUC‐
TURE
Statuses and value of the
PO1 relay
Communication programming instructions
