PLX51-PBM Operation
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 109 of 196
DPV1 Class 1 Write
CIP Message:
Table 5.8 – DPV1 Class 1 Write Message
8 + Length of Data Payload
Request Data:
Table 5.9 – DPV1 Class 1 Write Request
The amount of time (in milliseconds) the PLX51-PBM waits for
a DPV1 response before timing out and responding to the
EtherNet/IP request with a Timeout Status.
The station number of the PROFIBUS device.
The DPV1 Slot number for the write request.
The DPV1 Index number for the write request.
The number of bytes that must be written.
The data that will be written to the specific address. The
number of bytes will be equal to the Data Length in the
request.
Response Data:
Table 5.10 – DPV1 Class 1 Write Response
This is the status of the DPV1 data exchange. See appendix
for the definitions of the returned status.
This is the extended status of the DPV1 data exchange. See
appendix for the definitions of the returned extended status.
The length of the data that was written.
