3.6 Module Download
Once the PLX51-PBM configuration has been completed, it must be downloaded to
the module. The configured IP address of the module will be used to connect to the
module.
To initiate the download, right-click on the module and select the Download option.
Figure 3.31 - Selecting Download
Once complete, the user will be notified that the download was successful.
Figure 3.32 - Successful download
Within the PLX50 Configuration Utility environment the module will be in the Online
state, indicated by the green circle around the module. The module is now configured
and will start operating immediately.
Figure 3.33 - Module online
