PLX51-PBM Setup
PROFIBUS DPV0/DPV1 Master or Slave to EtherNet/IP™ or Modbus® Gateway User Manual
ProSoft Technology, Inc. Page 59 of 196
3.9 Adding PROFIBUS DP Devices – Slave Mode
The user will need to add each PROFIBUS device to the PLX51-PBM, which can
then be configured. This is done by right-clicking on the PROFIBUS Devices item in
the tree and selecting Add PROFIBUS Device.
Figure 3.67 – Adding a PROFIBUS Field Device
When adding a PROFIBUS Device in Slave Mode, the user can select any of the
following devices to add:
Figure 3.68 – Selecting a PROFIBUS Field Device
Table 3.15 – Slave GSD Files
